Meet NJL6100/6106EV

Product introduce

Main technical parameters :
Vehicle model				6100/6106EV series
Battery brand				Chuangyuan/CATL
Main trolley type battery capacity (kwh)				169.344-338.534
Constant speed method driving range (km)				290-710
Length X Width X Height (mm)				10490 X 2550 X 3050,3250,3320
Wheelbase (mm)				5800 , 6100
F/R Tread (mm)				2097,2119/1860,1882
Number of passengers (person)				76/19-37,92/19-37
Maximum Climbing Slope (%)				≥18
Maximum speed (km/h)				69
30km/h braking distance (full load) (m)				≤9.5
Minimum turning radius (m)				≤11
Minimum ground clearance (mm)				≥116
Motor type				Permanent magnet synchronization
Maximum motor power (kw)				200,240
Rated power of motor (kw)				100,120
Maximum torque of motor (N · m)				2800
Maximum motor speed (r/min)				2800 , 2850 , 3000
Suspension				6 Bag air suspension
Tires				275/70 R22.5
Turn				Domestic hydraulic power steering
Braking				Front disc rear drum/front disc rear disc dual circuit air brake system
Market positioning:
• Diverse choices, low floor and low entrance configurations. • Main and branch lines or BRTs in large and medium-sized cities. • The operating mileage is 290-710km, with a large passenger flow.




Please contact us for more information on the specific vehicle and corresponding vehicle photo details.
